Meeting Controller Console for Video Conference
Meeting Controller Console for Video Conference, which adapts different meeting rooms to make it easy for content sharing by connecting with all devices such as Laptop, USB camera, Display, Video/Sound bar w/ or w/o switch.
- Support by QCS5430/6490 platform.
- EE design based on QCS5430.
- ID/MD design for final product.
- SW on QCS LA3.1 baseline.
Applications:
Build your meeting room system
Small Office
Conference Room
CMF
| Name | Finishing | Surface treatment | Material | Color | Remark | |
| 1 | TP+LCM | Glossy | Full lamination | Glass+LCD(7') | Black | |
| 2 | Bottom case | Spray Paint/Matte/UV coating | CNC | PC+ABS | Silver | |
| 3 | Foot pad | Mat | Model | Silicone | Black | |
| 4 | Keys | Spray Paint/Matte/UV coating | CNC | PC+ABS | Silver | |
| 5 | Top case | Paint/Matte/UV coating | CNC | PC+ABS | Silver | |
| 6 | Speaker | Die cutting | sekisui5230PSB+300+nylon air filter | Silver | ||
| 7 | Part Label | Glossy | Die cutting+Silk screen | metallized polyester | Silver |
Specifications of the Meeting Controller Pad
| Section | Item | Definition | Comments |
| Design | Form factor | Refer to ID&CMF | |
| Installment | table stand | ||
| HW platform | Chipset | Qualcomm QCS5430 | Reuse RB3-Gen2 mainboard and interpose board, customize video mezz |
| RAM | 6GB LPDDR4x | ||
| ROM | 128GB uFS | ||
| SW platform | OS | Android 13 | |
| Display&Touch Panel | Size | 6.95 inch | |
| Panel type | TFT LTPS | ||
| Resolution | 1920x1080 | ||
| Brightness | up to 450nits | ||
| View angle | above 160 degree | ||
| PPI | 316 | ||
| interface | MIPI 4 lane | ||
| TP spec | TDDI Incell multi-touch | ||
| Audio | MIC array | 2*Mic | |
| Speaker spec | 2W*2 | ||
| Power | Powerinput | POE power adaptor | |
| Connectivity | HDMI-in | micro HDMI | BYOD, content sharing |
| DP-in | USB Type-C | BYOD, content sharing | |
| DP-out | USB Type-C | DP-out | |
| UVC/UAC-out | data connection to host device | ||
| UVC/UAC-in | USB Type-A | accessories connection | |
| Ethernet | RJ-45 | PoE, data connection to host device | |
| WIFI | 2.4G/5G | WIFI display | |
| Hard key | Power | ||
| Volume up&down | |||
