关键特性
4x 4K 高品质宽视角摄像机：H120 FOV，索尼传感器 IMX415
• 接算法： 360° 拼接全景视频，会议室中的每个人都是主要参与者；
• 可自由调整客户自己的拼接算法。展示您自己的专有技术。
6x (3x) 带 DOA 的麦克风（可选）
• 高通公司 3x 麦克风 DOA；
• Thundercomm创通联达 6x 麦克风 DOA；
• 可自由调整为客户自己的 DOA 算法。
易于设置/连接
• 连接笔记本电脑或大屏幕；
• 启动会议应用程序： 团队或任何其他会议应用程序；
• 点击触摸板上的按钮即可切换模式。
丰富的应用场景
• 全景模式；
• 带有人员检测和扬声器跟踪功能的 ePTZ 模式。
人工智能算法
• 人员检测: 高通或创通联达的人员检测算法；
CMF 设计
| Name | Finishing | Surface treatment | Material | Color | Remark | |
| 1 | Camera Deco | Matte | Painting | PC+ABS | Silver Gray | |
| 2 | Top housing | Matte | Painting | PC+ABS | Silver Gray | |
| 3 | Speaker mesh | Mesh | ||||
| 4 | Bottom housing | Matte | Painting | PC+ABS | Silver Gray | |
| 5 | Top case | Light | Raw material | Acrylic | Transparent | Silk screen |
| 6 | Bottom case | Matte | Raw material | Silicone | Black |
硬件架构
摄像头设计
CMOS 传感器 IMX415：
• 图像尺寸 对角线 6.4 毫米 ½.8 英寸
• 分辨率 3840*2160
• 单元尺寸 1.45 微米
• HDR 多重曝光，数字重叠
摄像头镜头:
• 焦距 1.9 毫米±5%。
• F No. 2.4
• 结构 3G5P
• 视场角 H120.3, V79.7, D130.3
• TV 畸变 -7.4%
• RI 47%
• 对焦范围 0.2m-inf
• CRA 13.5°
Blink360 全景视频会议一体机 SPEC
| Section | Item | Definition | Comments |
| General | Product type | Video conference USB device for Host PC, Panoramic Camera+Audio all-in-one on table | Product use case as attached picture |
| Key parts | Core boards, 4K camera*4 ,Single 8W speaker unit, 6-MIC array module. | ||
| OS | Android 13 | ||
| ID/ME Form | Dimension&Weight | 1223g, Height 300mm, Diameter 90mm | |
| Mechanical Form | Cylinder or Square column Form | ||
| CMF | Refer to ID | ||
| Core HW | Chipset | QCS6490 | Thundercomm C6490 SOM |
| Memory | uMCP 128GB UFS+6GB LPDDR4x | Optional 128+8GB | |
| PMU | Chipset | ||
| WIF/BT | WCN6856 | ||
| Audio PA | WSA8835 | ||
| Camera SPEC | Sensor | IMX415, 1/2.8 inch , CMOS, 8.29 M pixel, 1.45um unit cell | |
| Lens | HFOV>120, VFOV>80, TV distortion lower than-7.5%, Fno>2.4 | ||
| DOF | 0.5m to inf | ||
| Single Output resolution | 3840*2160@30fps | ||
| Stitching Output | HFOV360, VFOV>60 | ||
| Camera sync | Support Frame sync, 2A sync output | ||
| Connectivity | WIFI | 802.11 a/b/g/n/ac/ax, dual band 2.4Ghz/5Ghz, 2*2 MU-MIMO | |
| Bluetooth | BT5.2 | ||
| USB-C | PC to device through one USB-C, support type C alt mode | ||
| Ethernet1 | support 100/1000M ethernet | Convert from PCIe | |
| I/O Port | USB | Type C USB 3.0*1 device mode for PC connection | |
| HDMI out | HDMI 2.0 out*1 up to 1080P@60 | ||
| Power port | DC I/F，12V/3A | ||
| POE | support*1 | ||
| Debug port | Support Uart to micro-USB | only for debug | |
| Encoding stream output(Panorama) | 3840*576@30, 1920*288@30, Mjpeg, H.264 | ||
| Cropping streams output | 1280*720@30, 960*540@30, 640*360@30, H.264 | Only For people tracking up to 4 | |
| Composite stream output | 3840*2160@30, 1920*1080@30,Mjpeg, H.264 | ||
| HDR | NA | ||
| Auto exposure | Support | ||
| AWB | Support | ||
| Latency | TBD | ||
| Audio processing | Microphone | 6-DMIC circular array, SNR>69dB,AOP>130dB, sensitivity>-36dB | Top placement |
| Speaker | Single mono full frequency range speaker, Max Output 95dB SPL @8.0W，0.5m, Frequency response 100 Hz-20 KHz, THD 1kHz < 2%, Sampling rate 48Khz, | Bottom placement | |
| ANS(Active Noise suppression) | Support, suppress background noise and non-human noise | ||
| AEC(Acoustic Echo Cancelling) | Support, speaker echo collection, full duplex talk | ||
| Sound localization | 360 degree 2D-DOA , Within 5m distance | ||
| on/off control | MIC mute | ||
| Others | DC Power supply | DC 12V, 3A (MAX) | support OV, surge protection, |
| LED indicator | RGB LED*1 on TOP | ||
| Antenna | Internal Antennas for WIFI/BT | ||
| Buttons | Mute button*1 | on MIC board | |
| Volume button*2 | |||
| Function button*1 | |||
| Reset *1 | on main board | ||
| EDL switch*1 | |||
| AI | Video AI | People detection with stitched image | |
| Audio AI | DOA supported for speaker’s orientation | ||
| Hybrid AI | Speaker Tracking | ||
| AI mode | Switch between People Framing mode and Speaker Mode | ||
| Video | Video Source | 4 MIPI camera 4K30 | IFE x3 , IFE-lite + BPS x1 |
| Stitching | Stitching 4 4k30 camera input to 7680x1152@30fps as 360 panorama image, Output 7680x1152@30fps and 3840x576@30fps | ||
| Attendees cropping | Cropping 4 attendees from stitched stream when people Framing mode | ||
| Speaker Zoom | Zooming in for tracking speaker when Speaker mode | ||
| Encoding | H264 and MJPEG | ||
| Video Sink | Multi-stream output via multi standard UVC instances Panorama, Speaker tracking OR 4 attendees | ||
| IQ | 2A Sync | ||
| Audio | Audio Source | 6 Mics OR 3 Mics for DOA and UAC output | |
| UAC Speaker Device | |||
| Algorithm | DOA, ANS, AEC, AGC | ||
| Audio Sink | UAC mic device |
